16 zone Fire Alarm Control Panel CP1016 多线火警主机 16防区
产品详情
产品评论(0)

多线火灾报警控制系统(Conventional Fire Alarm Control system):区别于 总线火灾报警控制系统(addressable Fire Alarm Control system)。

多线火灾报警,是一种落后于总线报警的系统。在国内,消防规范所要求备有消防火灾报警系统的场合必须使用总线系统。如果不是公共场合,比如私人别墅;或者其他非强制安装火灾系统的地方,比如变压站,通信基站等,则可以选用。此外,根据工程需要,也可利用多线系统的配套功能,比如需要多线控制器来联动开关量类型的设备等。

在国外,则普遍用于别墅,小场合酒店,宾馆,民居。因此,东南亚和非洲等地区需求比较大。

一、多线报警控制器Conventional Fire Alarm Control panel)——简称多线主机或者多线控制器;多线控制面板等。

  主要特点:供电电压AC90-270V,  输出电压 DC24V  每回路接设备25个;

备电:需配212V/7A的铅酸蓄电池否则会报备电故.界面显示:每个烟感回路有对应的故障和火警显示灯,以及主电,备电,静音(声光),消 音(主机),总故障,火警,报警输出回路的显示灯。

二、多线烟感/温感/烟温复合:多线探头是通用的,可接于任何多线主机中。也可配套卷帘门控制箱使用。探头报警之后,会以拉低电压的方式将信号反馈给控制器。门灯(Remote LED)直接接于烟探底座上。烟探报警后会启动对应的门灯。

三、手动报警按钮(Conventional Manual Call Point),工作电压为DC24V,接线方式有常开接法和常闭接法(插钥匙或拔钥匙启动报警),以及串联(参与串联的手报全部同时动作才可启动报警)和并联接法。手报和烟感接于同一回路中。

四、声光报警器(Sound and light alarm/ Sound Strobe),工作电压:DC24V,现场声光报警,接于报警输出回路,起到火警警告和疏散的作用。频闪(Strobe),警铃(Bell),与声光类似。

1. Introduction
The fire alarm control panels (4 Zones, 8 Zones, and 16 Zones) provide all of the
sophisticated features required of a leading edge conventional fire alarm system along
with the simple operation and efficient installation methods demanded by both
installers and building users.
The panel can be flush or surface mounted and the generously sized metal back box
allows ample space for rear or top cable entries.
A comprehensive range of auxiliary devices is available to operate with the fire
control panels including optical, ionization, photoelectric, and heat detectors.
Each of the system components has been specifically designed to operate as part of
the system. This provides assurance that the control panel, smoke detectors,
interface devices and the ancillary components are all fully compatible with one
another and that the full range of system functionality is supported by each device.
1.1 Product features
The panels have the following key features:
· 4, 8, or 16 conventional input zones.
· 2 notification appliance circuits (NAC, Sounder) with built-in
synchronization for ANSI 3.41and Gentex.
· The panel comes with a 3 amp power supply.
· Dedicated alarm and fault relays.
· 1 RS485 can be able to connect repeaters.
· Enclosure supports two 12V, 7Ah backup batteries.
